1 Scope This document gives rules for definition and interpretation of general geometrical specifications and general size specifications defined according to ISO 8015:2011, 5.12. General specifications defined in other standards, and the link to these standards, are not covered by this document. The general geometrical specifications and general size (linear or angular) specifications defined in this document apply only to integral features (including features of size). These specifications do not apply to derived features or integral lines (see ISO 17450-1 for the definitions of integral features and derived features). Dimensions other than linear or angular sizes (see ISO 14405-2) are not covered by this document. 2 Normative references The following documents are referred to in the text in such a way that some or all of their content constitutes requirements of this document. For dated references, only the edition cited applies. For undated references, the latest edition of the referenced document (including any amendments) applies. ISO 8015, Geometrical product specifications (GPS) — Fundamentals — Concepts, principles and rules ISO 17450-1, Geometrical product specifications (GPS) — General concepts — Part 1: Model for geometrical specification and verification ISO 17450-2, Geometrical product specifications (GPS) — General concepts — Part 2: Basic tenets, specifications, operators, uncertainties and ambiguities ISO 22432, Geometrical product specifications (GPS) — Features utilized in specification and verification ISO 25378, Geometrical product specifications (GPS) — Characteristics and conditions — Definitions 3 Terms and definitions For the purposes of this document, the terms and definitions given in ISO 8015, ISO 17450-1, ISO 17450-2, ISO 22432 and ISO 25378 and the following apply. ISO and IEC maintain terminological databases for use in standardization at the following addresses: — ISO Online browsing platform: available at https://www.iso .org/obp — IEC Electropedia: available at http://www.electropedia .org/ 3.1 general geometrical specification geometrical specification indicated in the technical product documentation (TPD) which is not an individual specification
3.2 general size specification size specification (linear size specification or angular size specification) indicated in the technical product documentation (TPD) which is not an individual specification Note 1 to entry: Linear size specifications are defined in ISO 14405-1. Angular size specifications are defined in ISO 14405-3. 3.3 integral feature geometrical feature belonging to the real surface of the workpiece or to a surface model Note 1 to entry: An integral feature is intrinsically defined, e.g. skin of the workpiece. Note 2 to entry: For the statement of specifications, features obtained from partition of the surface model or of real surface of workpiece shall be defined. These features, called “integral features ”, are models of the different physical parts of the workpiece that have specific functions, especially those in contact with the adjacent workpieces. Note 3 to entry: An integral feature can be identified, for example, by: — — — a partition of the surface model; a partition of another integral feature; a collection of other integral features. [SOURCE: ISO 17450-1:2011, 3.3.5] 4 Basic principles 4.1 General When using general geometrical specifications or general size specifications, the designer should be aware of the following risks: — overlooking important functional requirements; — selecting unnecessarily tight tolerances regarding the functional requirement. It is the responsibility of the designer to ensure that: — functional requirements are properly defined; — the geometrical features influencing the functions are properly specified; — the entire part, i.e. all geometrical features, is completely and unambiguously specified. General geometrical specification and general size specification are ways of minimising the number of indications in a TPD.
